- Excellent 1D scanning performance
- Captures virtually all 1D bar codes on any surface — including mobile phone displays
- Industry-leading working range
- Compatible with 123Scan2 and Scanner Management Service (SMS)
- Superior motion and angular tolerance
- International keyboard support
- Withstands 100+ consecutive drops to concrete and 1,000 consecutive 1.64 ft./ 0.5 m tumbles
Specifications
Physical Characteristics
- Dimensions: 16 cm H x 6.7 cm W x 9.9 cm L
- Weight: 140 grams
- Voltage and Current: 5VDC ± 10%
* <165 mA scanning
* <40 mA standby
* <2.5 mA USB suspend
* <4.0 mA low power mode (when enabled, RS232 and Keyboard Wedge only)
- Power Source: Host power or external power supply
- Color: Twilight Black
- Supported host interfaces: USB, RS232, Keyboard Wedge and IBM RS485
- Keyboard Support: Supports over 90 international keyboards
Performance Characteristics
- Skew Tolerance: ±45°
- Pitch Tolerance: ±45°
- Roll Tolerance: ±45°
- Scan Pattern: Single bright aiming line
- Scan Angle: Horizontal 35°
- Scan Speed: 547 scans per second
- Motion Tolerance: 63.5 cm per second
- Light Source: LED Class 1 device 617mm (amber)
- Min. Print Contrast: 15% MRD
User Environment
- Ambient Light Immunity: Max 108,000 lux
- Operating Temp.: 0° C to 50° C
- Storage Temp.: -40° C to 70° C
- Humidity: 5% to 95% RH, non-condensing
- Drop Specs: Over 100 drops at 5 ft./1.5 m at room temperature; survives 6 ft./1.8 m drops to concrete
- Tumble Testing: 1,000 cycles (2000 drops) in 1/2 meter tumbler
- Environmental Sealing: IP42
- Bar Code Symbologies: UPC/EAN: UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN Format, UCC Coupon Extended Code, ISSN EAN Code 128 Including GS1-128, ISBT 128, ISBT Concatenation, Code 39 including Trioptic Code 39, Convert Code 39 to Code 32 (Italian Pharmacy Code), Code 39 Full ASCII Conversion Code 93 Code 11 Matrix 2 of 5 Interleaved 2 of 5 (ITF) Discrete 2 of 5 (DTF) Codabar (NW - 7) MSI Chinese 2 of 5 IATA Inverse 1D (except all GS1 DataBars) GS1 DataBar including GS1 DataBar-14, GS1 DataBar Limited, GS1 DataBar Expanded
