Main Features: - The main input voltage is 230 B - Other Input voltage 220 B; 240 B - The main output voltage is 230 V - Other Output voltage 220 V; 240 V - Rated power [W] 6000 W - Rated power of 6000 VA - Output connection type 6 IEC 60320 C13; 2 IEC Jumpers; 4 IEC 60320 C19 - Type of output connection All-in-one three-wire (H N + E) 1 - Number of Unit 4U - Battery type Lead acid battery Common: - Product subcategory web - High density - The number of slots unoccupied by power modules is 0 - Number of slots occupied by power modules - 0 - Spare - No Physical parameters: - The Color is Black - Height 17.4 cm - Width 43.2 cm - Depth 71.94 cm - Net weight 60 kg - Installation location - Front - Type of fastener - Bottom - Mounting design - Rack-mounted - Two-support mount - 0 - USB-compatible - Yes - Mounting position - Horizontal Entrance: - Network frequency 40-70 Hz auto detection - Number of input connections 1 All-in-one three-wire (1P + N + E) - Input voltage limits of 100...275 V adjustable (for half load) Output: - Maximum set power (W) - 6000 W - Harmonic distortion - Less than 2% - Output frequency - 50/60 Hz +/- 3 Hz synchronized with the power grid - Cross factor - 3:1 - UPS type - Dual conversion topology - Type of voltage form - Sinusoidal signal - Bypass type - Internal bypass (automatic and manual) - Maximum set power (VA) - 6000 VA Accordance: - CE; EAC; IRAM; RCM; VDE certificates - Marking - CE mark - Standards - EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 Environmental parameters: - Ambient operating temperature - 0...40 °C - Relative humidity - 0...95% without condensation - Altitude above sea level - 0...10000 ft - Ambient temperature during storage -15...45 °C - Relative humidity of storage - 0...95% without condensation - Storage height - 0.00...15240.00 m - Acoustic level - 55 dBA - Heat transfer - 1300 ‰ - Degree of protection IP - IP20 Batteries and battery life: - Pre-installed batteries - 0 - Typical recharge time is 1.5 h - Number of RBC™ cartridges - 1 - Battery voltage - 192 V - Charger power (W) - 597 W rated - Battery capacity in volt-ampere hours - 902 vach working time - Battery life - 3...5 year(s) - Spare battery - APCRBC140 - Battery options - SRT192RMBP 1 2706 VACH SRT192RMBP 2 4510 VACH SRT192RMBP 3 6314 VACH SRT192RMBP 4 8118 VACH SRT192RMBP 5 9922 VACH SRT192RMBP 6 11726 VACH SRT192RMBP 8 15334 VACH SRT192RMBP 10 18942 VACH - The possibility of increasing the time of autonomy - 1 Communication tools and admin tools - Free slots - 1 - Alarm - Audible and visible alarms : prioritized by severity - Emergency Power Off (EPO) - Yes Protection against voltage surges and filtration: - Rating according to the level of absorbed energy of the vsp - 480 J
