Main Features: - Main Input voltage 208 B, 230 B - Other Input voltage 220 B, 240 B - The main output voltage is 230 V - Other Output voltage 208 B, 220 V, 240 V - Rated power [W] 2700 W - Rated power 3000 VA - Input Connection Type IEC 320 C20, Schuko CEE 7 / EU1-16P, BS1363A British - Output connection type - 8 IEC 320 C13? 2 IEC Jumpers, 2 IEC 320 C19 - Number of Unit 4U - Length - 1.83 m - Number of cables - 1 - Battery Type - Lead acid battery Common: - The number of power modules is 2400 - The number of slots occupied by power modules is 0 - The number of slots unoccupied by power modules is 0 - Product subcategory web - Extended run - Spare - No Physical parameters: - The Color is Black - Height 43.2 cm - Width 17.8 cm - Depth 48.3 cm - Net weight 38.64 kg - Installation location - Front - Type of fastener - Bottom - Mounting design - Rack-mounted - Two-support mount - 1 - USB-compatible - Yes Input: - Input voltage limits 140...280 V - Network frequency 50/60 Hz +/- 3 Hz auto detection Output: - Cross factor 3:1 - Harmonic distortion Less than 5% - Maximum set power (VA) - 3000 VA - Maximum set power (W) - 2700 W - Switching time The typical time is 6 ms, the maximum is 10 ms - UPS type is Linearly interactive - Type of voltage form - Sinusoidal signal - Output frequency - 50/60 Hz +/- 3 Hz synchronized with the power grid Accordance: - Certificates - CE, EAC, IRAM, RCM, TISI, VDE - Standards - EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018 Environmental parameters: - Acoustic level - 55 dBA - Heat transfer - 184 ‰ - Altitude above sea level - 0...10000 ft - Operating ambient temperature - 0...40 °C - Ambient temperature during storage -15...45 °C - Storage height - 0.00...15240,00 m - Relative humidity - 0...95 % - Relative humidity of storage - 0...95 % Batteries and battery life: - The possibility of increasing the time of autonomy - 1 - Pre-installed batteries - 0 - Free battery compartments - 0 - Typical recharge time is 3 h - Number of RBC™ cartridges - 1 - Battery life - 3...5 year(s) - Battery capacity in volt-ampere hours - 738 vach operating time - Charger power (W) - 245 W rated - Battery options SMX120BP 1 2214 VACH, SMX120BP 2 3690 VACH, SMX120BP 3 5166 VACH, SMX120BP 4 6642 VACH, SMX120BP 6 9594 VACH, SMX120BP 8 12546 VACH, SMX120BP 10 15498 VACH Communication tools and admin tools: - Control panel Multifunction LCD status and control panel - Emergency Power Off (EPO) - Yes - Free slots - 1 - Control panel LED status display with on line : on battery : replace battery and overload indicators - Alarm - Alarm when on battery : distinctive low battery alarm : configurable delays Protection against voltage surges and filtrations: - Rating according to the level of absorbed energy vsp - 645 J - Noise suppression Permanent multi-pole noise filter : residual voltage amplitude 0.3% according to IEEE standards : voltage surge limitation without time delay : compliance with UL 1449 requirements
