Details Type Mainboard EAN 4710483949333 Manufacturer no. 90-MXBQ00-A0UAYZ Base AM5 Max. supported CPUs 1 Operating system Support Windows 10 ready, Windows 11 ready Processor Supported models Ryzen 5 7xxx (Raphael), Ryzen 5 7xxxX (Raphael), Ryzen 5 7xxxF (Raphael), Ryzen 5 8xxxG (Phoenix), Ryzen 5 9xxxX (Granite Ridge), Ryzen 7 7xxx (Raphael), Ryzen 7 7xxxX (Raphael), Ryzen 7 7xxxX3D (Raphael), Ryzen 7xxxX3D (Raphael), Ryzen 7xxxX3D (Raphael), Ryzen 7xxxX3D (Raphael), Ryzen 7xxxX3D (Raphael), Ryzen 7xxxX3D (Raphael), Ryzen 7xxxX3D (Raphael), Ryzen 7xxxX (Raphael), Ryzen 7 7xxxX3D (Raphael), Ryzen 7xxxX (Raphel), Ryzen 7xxxX (Raphael), Ryzen 7xxxX3D (Raphael), Ryzen 7 7xxxX3D (Raphael), Ryzen 7xxxxxxxX (Granite Ridge), Ryzen 9 7xxxx (Raphael), Ryzen 9 7xxxxX (Raphael), Ryzen 9 7xxxxX3D (Raphael), Ryzen 9xxxX (Granite Ridge) Chipset AMD X870 Slots PCIe x16 2x (thereof: 1x PCIe x16, 1x PCIe x4) BIOS 256Mb Flash ROM UEFI AMI BIOS Form factor E-ATX Power supply ATX12V (24-pin + 2x 8-pin) Memory maximum 256 GB Number of plinths 4x DDR5 Supported standards DDR5 8200 / 5200 / 4800 / 4400 Channels 2 Maximum memory storage space 8 Connections (external) USB-A 3.2 Gen 1 (5 Gbit/s) 4 USB4 2 USB-A 2.0 6 6 HDMI 1 Microphone 1 Line-out 1 S/PDIF-Out (optical) 1 RJ-45 1 Bluetooth Yes Wi-Fi Yes Connections (internal) SATA 4 M.2 3 M.2 Module Key M M.2 interface PCIe M.2 length 80 - 80 mm RGB LED Header 1 addressable RGB LED Header 3 USB-C 3.2 Gen 2x2 (20 Gbit/s) 1 4-pole PWM fan 7 Connections (optional) USB 3.2 Gen 1 (5 Gbit/s) 2 USB 2.0 4 RGB standard RGB LED SATA controller AMD X870 directly usable RAID level 0, 1, 10 USB controller AMD X870 Onboard graphics The graphic connections of the motherboard can only be used when using a CPU with an integrated graphic chip. LAN Dragon RTL8125BG 2.5Gb Ethernet Wi-Fi 7 + Bluetooth 5.4 Features 2x USB4 DisplayPort Video outputs | Support for DisplayPort 1.4 and HDR. Further information To support the latest processor cores, a BIOS update may be required. Accessories available 2 x SATA data cable, 2 x ASRock WiFi 2.4/5/6 GHz antenna Dimensions Width: 244 mm x height: 305 mm
