Details Type Mainboard Color white EAN 4895106296909 Manufacturer's No. 52122-02-40G base AM5 Supported Maximum CPUs 1 operating system Support Windows 10 ready, Windows 11 ready processor Supported models Ryzen 5 7xxx (Raphael), Ryzen 5 7xxxX (Raphael), Ryzen 5 7xxxF (Raphael), Ryzen 5 7xxxX3D (Raphael), Ryzen 5 8xxxF (Phoenix), Ryzen 5 8xxxG (Phoenix), Ryzen 5 9xxx (Granite Ridge), Ryzen 5 9xxxX (Granite Ridge), Ryzen 5 9xxx Chipset AMD X870 Slots PCIe x16 2x (of which: 1x PCIe x16, 1x PCIe x4) PCIe x1 1 BIOS EFI BIOS Yeah, yeah Form factor ATX Use PC Power supply ATX12V (24-pin + 2x 8-pin) Memory Maximum maximum 256 GB Number of sockets 4x DDR5 Supported standards DDR5 up to 8400 MT/s Channels 2 Maximum storage ranks 8 Memory controller in CPU Yeah, yeah Maximum data density 8192 Mbit Connections (external) USB-A 3.2 Gen 2 (10 Gbit/s) 1 USB-A 3.2 Gen 1 (5 Gbit/s) 4 USB4 1 Note: The designation USB 3.2 Gen 1 corresponds to the earlier designations USB 3.1 Gen 1 or USB 3.0. The designation USB 3.2 Gen 2 corresponds to the earlier designations USB 3.1 Gen 2 or USB 3.1. USB-A 2.0 2 HDMI 1 DisplayPort-Out 1 Microphone 1 Line-In 1 Line-Out 4 RJ-45 1 Bluetooth Yeah, yeah WLAN Yeah, yeah Connections (internal) HOURS 4 M.2 3 M.2 Module Key M M.2 Interface PCIe Connections (optional) USB 3.2 Gen 1 (5 Gbit/s) 2 USB-C 3.2 Gen 1 (5 Gbit/s 1 USB 2.0 4 TPM Yeah, yeah SATA Controller AMD X870 Directly usable RAID levels 0, 1, 10 USB Controller AMD X870 Onboard Graphics The graphics ports of the motherboard can only be used when using a CPU with an integrated graphics chip. Sound Realtek ALC897 AND Realtek RTL8126G 5G LAN WiFi 7 + Bluetooth 5.4 Further information To support the latest processor cores, a BIOS update may be required. Dimensions Width: 245 mm x Height: 305 mm Warning and safety instructions Warnings: Attention: Product contains a button cell or battery coin.
