Vertex GX-1200 Technical Specifications 80PLUS ® Gold Cybenetics Efficiency Level Gold (See report) Cybenetics Noise Level Lambda A- (See report) Form Factor Intel ATX 12 V Dimensions 160 mm (L) x 150 mm (W) x 86 mm (H) Fan Information Fan Size 135 mm Fan Control Digital Fan Control Fan Bearing Fluid Dynamic Bearing Life Expectancy 50,000 hours at 40 °C, 15 % - 65 % RH Cable Information Modularity Fully Modular Cable type Flat black cables Electrical Features Operating Temperature 0 - 50 °C MTBF @ 25 °C, excl. fan 100,000 hours AC Input Full Range Protection OPP, OVP, UVP, OCP, OTP, SCP Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH Warranty 12 Years Power Output AC Input Voltage: 100 V - 240 V Current: 15 - 7.5 A Frequency: 50 Hz - 60 Hz DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB Maximum Power 25 A 25 A 100 A 0.3 A 3 A 125 W 1200 W 3.6 W 15 W Total continuous power 1200 W Cables Vertex GX-1200 Cable type Connector(s) per cable Total Length (mm) Number(s) of cable(s) included  MB (24/20 pins) 1 610 1 CPU (8/4 pins) 1 700 2 PCIe (8/6 pins) 2 750 0 PCIe (8/6 pins) 1 750 3 SATA 4 950 0 SATA 4 950 4 SATA 4 760  0 SATA 3.3 2 550 1 SATA 2 570 0 SATA 2 470 0 SATA 3.3 2 550 0 Molex 3 690 1 Molex 2 470 0 Molex to SATA 3.3 Adapter 2 300 0 Molex to FDD Adapter 1 101  0 12VHPWR 1 (16 Pins to 16 Pins) 750 1
