Intel Core? Ultra 5 250K Plus (tray version)

The Intel® CoreTM Ultra desktop processors support Intel® AI Boost technology and have a chip layout with different CPU cores for different application scenarios. The Performance Cores ensure performance in computing-intensive applications, while the Efficiency Cores ensure energy efficiency with low loads. The CoreTM Ultra processors support PCIe Gen 5.0 and 4.0 as well as DDR5. The processor is compatible with motherboards based on the Intel® 800 chipset.

Desktop type
Manufacturer no. AT807683B9B4886
CPU type Core Ultra 5
Base 1851
FC-LGA4 design
Max supported PCIe version 5.0
Core name Core Ultra 5 2xxK (Arrow Lake)
Core number 18 cores
Core Threads 18
Core microarchitecture Arrow Lake
Core clock frequency 4200 MHz
Core Turbo mode up to a maximum of 5300 MHz
Core Core Type 1 Performance, 6 cores, 6 threads
Core clock frequency base clock 4,200 MHz, boost clock 5,300 MHz
Core Core Type 2 Efficiency, 12 cores, 12 threads
Core clock frequency base clock 3,600 MHz, boost clock 4,600 MHz
AI core number 1
AI Core Performance (TOPS) 13
Cache Level 2: 30720 KB, Level 3: 30720 KB
Fan No fan included
CPUs in multiprocessor system 1
Memory Controller Supports ECC
Memory controller channels 2
Storage Controller Supported standards up to
Memory controller CU-DIMM
Graphics GPU Intel® Graphics
Graphics clock standard: 300 MHz, Turbo: 2000 MHz
Power consumption (TDP) 125 watts
Max. power consumption (TDP) 159 watts
Feature Intel® AI Boost: OpenVINOTM | WindowsML | DirectML | ONNX RT | WebNN
Note tray version
